    Solar Panel Battery Charger 3W Mini Laminated Solar Power Panel ZW-3W-9V-2 Aluminum Frame 9V

    Ask Lasest Price
    Brand Name : ZHIWANG
    Model Number : ZW-3W-9V
    Certification : CE EMC ROHS
    Price : USD $4.5
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 1000SETS
    Delivery Time : 5 DAYS
    • Product Details
    • Company Profile

    Solar Panel Battery Charger 3W Mini Laminated Solar Power Panel ZW-3W-9V-2 Aluminum Frame 9V


    Product Description



    9V Portable Glass Solar Panel ZW-3W-9V-2 Tempered Laminated Solar Panels 3W Aluminium Sash Solar Charger


    Model:ZW-3W-9V-2
    Brand:Zhiwang
    Size:220mmx135mmx17mm
    Battery:18
    Size of Cell19.5mm*52mm
    Peak power:3W
    Max voltage:9V
    Max current:0.33A
    Open voltage:9.9V
    Short current:0.37A
    Weight:0.4KG
    Keyword:Glass Laminated Solar Panel
    Front Glass:3.2mm, High Transmission, Low iron, tempered Glass
    Standard Testing Conditions:

    AM1.5 E=1000W/m2 T=25℃ Luminous intensity: 38000Lux

    Test ambient temperature 25 ° C ±2 ° C
    The humidity of the test environment is 60%-70%
    Light intensity 40*1000 LUX
    The vertical distance of light is 30cm
    Open-circuit test multimeter
    Load the test dedicated test stand
    Application battery charging
    Storage environment 20cm above the ground;

    Humidity of 60% 70%; The normal temperature

    Raw Material:

    Glass and Plastic Frame

    Poly-crystalline or Mono-crystalline Silicon

    EVA-------excellent anti-aging EVA

    TPT-------TPT hot seal made of flame resistance

    Operating Temperature(°C)-40°C ~ + 85°C
    Maximum System Voltage10V(UL)/15V(IEC) DC
    Maximum Rated Current Series2A
    Temperature Coefficients of Pmax-0.435%
    Temperature Coefficients of Voc-0.35%
    Temperature Coefficients of Isc0.043%
    Nominal Operating Cell Temperature (NOCT)47+/-2°C
    Current temperature coefficient%/K0.06+/-0.01
    Voltage temperature coefficientmV/K-(78+/-10)
    Power temperature coefficient%/K-(0.5+/-0.05)

    Module characteristic:
    1. High conversion rate and efficient output Poly crystalline Silicon.
    2. Mini Solar Panels with excellent weak light effect to charge solar kits system.
    3. High quality and high transmittance of toughened glass special for mini solar panels.
    4. The unique process makes the components look strong and anti-snow, and easy to install.
    5. Special techniques to avoid Mini Solar Panels the freezing and deformation of water in the frame Suitable for all kinds of small power appliances, emergency lights, advertising lights, traffic lights, household lights, electric fans, such as solar water pumps, solar street lamps, small solar systems.
    6.Mini Solar Panels suitable for all kinds of small power appliances, emergency lights, advertising lights, traffic lights, household lights, electric fans, such as solar water pumps, solar street lamps, small solar systems.
    7. Quality solar cells with high solar energy conversion up to 19.5%.
    8. Mono-crystalline or poly-crystalline silicon solar cells are for options.
    9. Transparent low-iron tempered glass and anodized aluminum frame to ensure modules working in extreme outdoor environment.
    10. Lifespan up to 3 years for solar panel photo-voltaic.
    11. Circuit board 1.0mm board or 1.2mm board or 1.5mm board
    12. Silicon wafer 18% or more multi-chip or 20% or more single chip
    13. High transparency epoxy resin, PET, EVA film or semi-explosion-proof transparent glass
    14. Black high temperature protection strip sticking in.
    15. Packing method Carton packing


    Product specification
    Battery type monocrystalline silicon or polysilicon
    Product process plastic frame or aluminum frame
    Glass laminate
    Standard cable for the solar panel optional: Type -c male, 1m long, 1A, 5V SBU signal output
    International solar energy inspection standard: solar radiation 1000W/M², temperature 25℃, atmospheric quality AM15.
    The test conditions can be replaced by 500W halogen tungsten lamp, the illumination is adjusted to 38000LUX, and the test distance is 15CM.
    The test temperature shall be controlled at 25 ° C for no more than 30 minutes, and the high-temperature test at 60 ° C for no more than 1 minute.
    1. No shelter under the sun
    2. Operating temperature -20°C-80° C
    3. Iron temperature :360+10℃, welding time is not more than 3 seconds







    Solar Panel Battery Charger 3W Mini Laminated Solar Power Panel ZW-3W-9V-2 Aluminum Frame 9V

    Q. Are you a manufacturer or a trading company?

    A. We are two factories in Yuyao,Zhejiang and Xuzhou, Jiangsu, we can deal with OEM & ODM, customization available.

    Q. Is it OK to print my logo on solar paenl product?
    A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

    Q. What is your terms of packing?
    A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.

    Q. What is your terms of delivery?
    A: EXW, FOB, CIF. And other accepted payment method.

    Q. How about your delivery time?
    A: Generally, it will take 15 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

    Q. Can you produce according to the samples?
    A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

    Q. Do you test all your goods before delivery?
    A: Yes, we have 100% test before delivery.

    Q.How many years for warranty?

    A: Our warranty is 5 -10 years.
